Set width, depth, height, service clearance, and door approach.
Price:
$2000-$3500
Model:
SOP-OF106
Exterior Size
Customized
Internal Size:
Customized
Maximum Occupancy:
2-4 persons
Material:
1.5mm sheet metal+soundproof tempered glass, 15mm fireproof soundproof board+ polyester fiber acoustic board+eco-friendly soundproof cotton.
Power:
110 - 240V/50Hz & 12V-USB
Light:
4000K natural light
Voltage:
110-240V,50Hz customized
Weight:
850kg
Certification:
ISO CE
Customization control sheet | Privacy office pod
A customizable soundproof privacy office pod cannot be evaluated from a generic footprint. Both outside and inside dimensions are offered as customized, so the buyer's first deliverable should be a dimensioned boundary: available floor area, ceiling height, door approach, service clearance, and the clear space required inside.
The available specification describes occupancy for 2-4 persons and gives an initial weight of 850kg. Occupancy is not a finished layout, and the weight must be confirmed for the selected configuration. Seating type, table shape, screen position, camera distance, and door movement must fit the agreed internal dimensions before a quotation can be compared.
Set width, depth, height, service clearance, and door approach.
Show seats, table, screen, equipment, and user movement.
Choose the normal meeting size instead of relying on a 2-4 person range.
Document doors, lifts, corners, loading limits, and assembly area.
Mark power, sockets, data, lighting, and ventilation interfaces.
List the drawings, samples, and test documents required for approval.
Available product information references fiber-cement board with a vinyl floor surface, glass curtain-wall elements, aluminum external finishing, insulation, steel structure, tempered or laminated glass, fireproof soundproof board, polyester-fiber acoustic board, and soundproof cotton. A custom quotation should identify only the materials selected for this project.
Ask the supplier to issue a layer-by-layer schedule for the quoted pod, identifying the floor, wall, roof, glazing, interior treatment, external finish, thicknesses, and finish codes. Samples and drawings should carry the same project code so the approved construction can be traced through production and handover.
Draw the smallest normal group, the largest expected group, and the equipment used in each session. Four people in lounge seating create a different circulation path from two people facing a display. State whether calls, interviews, confidential discussions, or focused work are the main task, then show the table, screen, camera, and cable positions.
Available service information references 110-240V at 50Hz, connector customization, and 4000K natural light. Confirm the destination voltage, plug type, number and location of sockets, data requirement, lighting controls, ventilation arrangement, and equipment load. Smart controls and booking functions should be treated as optional scope until every included component appears in the quotation schedule.
ISO and CE are referenced in the available product information. If either is required, request the applicable documents and check their project or model scope and destination relevance. A general label is not a substitute for document review.
The outside and inside dimensions are customized. The supplier should confirm the outer envelope and clear internal dimensions on an approved project drawing.
Use one model or project code on the quotation, configuration drawing, material schedule, service drawing, and supporting documents.
Request a layer-by-layer schedule for the quoted configuration, then approve the stated floor, wall, roof, glazing, interior treatment, external finish, thicknesses, and finish samples.
| Model | Soundproof Privacy Booth |
|---|---|
| Outside Dimensions | Customized |
| Inside Dimensions | Customized |
| Flooring | 18mm fiber cement board + 4mm vinyl surface |
| Wall | Glass curtain wall with arc-shaped edge |
| External Finishing | 2.5mm aluminum curtain wall (fluorocarbon coating) + Glass wool insulation |
| Structure | Galvanized roof forming steel + light luxury decoration style |
Dimensions are customizable to suit your space. Please confirm your required internal and external measurements with our team to ensure the pod fits your intended layout and access route.
