Price:
$1600-$2000
Model:
SOP-FH104
Exterior Size
2100x1600x2200m
Internal Size:
1900x1400x1940mm
Maximum Occupancy:
2-4 persons
Material:
steel
Power:
110V-240V/50HZ.
Light:
4000K / 1600Lsx natural lighting system
Voltage:
110-240V
Weight:
800 kg
Certification:
ISO CE
Household allocation brief · SOP-FH104
A soundproof pod for home can support more than one routine, but work calls, reading, meditation, and shared conversation do not ask the glass-enclosed interior to do the same thing. Choose the primary activity and busiest time window first. Furniture, cable placement, airflow expectations, and household booking rules can then follow a real use pattern instead of a broad promise of quiet.
| Primary activity | Layout question | Configuration to confirm |
|---|---|---|
| Remote work | Where do screen, chair, and cables sit? | Power location, network route, lighting, furniture |
| Online meetings | Can the camera frame work without blocking entry? | Internal clearance, glare control, ventilation |
| Reading or meditation | How long will one person remain inside? | Airflow, light level, seating, household availability |
| Shared use | Will two to four people sit or stand? | Usable layout, heat load, door approach, occupancy plan |
The external envelope and listed 800 kg weight make the delivery path part of product selection. Measure entrances, corridors, turns, lift dimensions, ceiling clearance, and the assembly area. Mark the 2100x1600mm footprint on the intended floor and add door movement and service access. Confirm floor suitability with the responsible project professional.
The available specification describes steel construction and a glass enclosure, and an application entry mentions Outdoor. That label does not provide weather-resistance, water-ingress, or IP evidence. Keep exterior placement outside the approved scope until the supplier identifies a documented outdoor build and its protection requirements.
The specification lists two 120 mm oil-bearing ventilators at 12VDC, 1500 +10% RPM, and 3.24W, plus 110V-240V/50Hz power. Confirm airflow arrangement, control method, regional connection, maintenance access, and expected use duration for the exact layout.
A 40dB value with a ±10dB notation appears in the available specification. Ask for the supporting test method, specimen, and installation condition before using it in a comparison. Glazing can preserve visual openness, but a picture of glass does not establish isolation performance.
A home pod used by several people needs more than a capacity label. Record who can book it, whether calls or quiet reading take priority, how long sessions normally last, and who reports a ventilation or electrical fault. Locate it so one household member can enter without repeatedly disturbing another room.
An available lighting entry lists 4000K together with the unclear string “1600Lsx.” Ask the quotation to state the light specification in a recognized unit and identify the switch or control arrangement. If screens or video calls are the primary task, review glare and camera position with the confirmed glazing and furniture plan.
The available specification lists two to four people, but the usable arrangement depends on the primary activity, furniture, entry clearance, and session duration. Confirm those items on a quotation drawing.
An available application entry includes Outdoor, but no weather-resistance or IP evidence is provided. Treat outdoor placement as unverified until the supplier documents an outdoor configuration and its protection requirements.
Request the supporting report for the quoted configuration, including the test method, specimen, installation condition, and meaning of the listed 40dB with ±10dB notation.
| Sound insulation | 40dB (±10dB) |
|---|---|
| Size | 2100x1600x2200mm |
| Power Supply System | 110V-240V/50HZ |
| Ventilation system | Two 120mm oil-bearing ventilators (12VDC), 1500+10% RPM speed / 3.24W |
| Application | Home Office, Outdoor, Hotel, Office Building, Hospital, School, Mall, Sports Venues |
